R271558: Dowel Pin

Part Number: R271558

Parts Tier: Original

Precision-engineered dowel pin designed for accurate alignment and secure fastening in various mechanical assemblies
Key specifications: 5.30 mm (0.21 in) length, 31.77 mm (1 1/4 in) outer diameter, 22.30 mm (7/8 in) diameter, ideal for precise fit and alignment
Additional specs: 14 mm (0.55 in) thread size with a 2 TPI pitch, ensuring robust and reliable fastening in heavy-duty applications
Made from high quality general steel, offering superior strength and durability for long-lasting performance
Finished with a zinc coating to provide excellent corrosion resistance and enhanced longevity in demanding environments

Product Dimensions

Weight

0.03 lb

Height

0.75 in

Length

1.25 in

Specifications

Diameter

22.3 mm

Outside Diameter

31.775 mm

For the most accurate fit and confidence, please select the equipment you are shopping for. Parts can be used across a number of different models, the models shown here indicate general fit of the part.

6B-954
6B-1404
6BH 110
6E-1004
6E-1204
6E-1204P
6E-1404
6E-1404L
6E-1404P
6E-1404PL
6E-1504L
6E-1504PL
1354
1404
6095B
6100D
6100E ROSARIO
6100E SALTILLO
6105D
6105E
6105EH
6110B
6110D
6110E ROSARIO
6110E SALTILLO
6115D
6115E
6120B
6120E
6120EH
6125D
6125E ROSARIO
6125E SALTILLO
6130D
6130E SALTILLO
6135B
6135E
6140B
6140D
6140E
6150B
6403
6403HC
6603
6803
